Small Size Spi Camera Interface CMOS Sensor GC6133 Camera Module

Specificaitons

Description

The GC6133 is a highly integrated CMOS image sensor, active pixel is 240 x 320. GC6133 outputs YUV/YCrCb 4:2:2 or RGB 565 data through the serial data bus. GC6133 supports SPI interface. The on-chip ISP provides a very smooth AE (Auto Exposure) and accurate AWB (Auto White Balance) control. It has a commonly used two-wire serial interface for host to control the operation of the whole sensor.

Features

◆Standard optical format of 1/13 inch

◆Various output formats: YCbCr4:2:2 / RGB565 / Raw Bayer

◆Windowing support

◆SPI interface: 1-wire, 2-wire

◆Horizontal/Vertical mirror

◆Image processing module

◆Package: CSP

Applicaitons

Notebook and desktop PC cameras

PDAs

Toys

Digital still cameras and camcorders

Video telephony and conferencing equipment
