13MP IMX258 Fixed Focus USB2.0 Camera Module
Product Description:
This is a 13MP IMX258 fixed focus USB2.0 camera module. It adopts
USB2.0 camera module interface, plug and play, no need for
additional driver, low latency transmission. It is USB compatible
with multiple platforms, compact design, easy to carry, view angle
is D78.4°, distortion is <-1.5%. At present, it is mainly used
in industrial equipment, smart home and monitoring equipment.
Features:
1.USB 2.0 High-Speed Transmission: 480Mbps bandwidth for real-time HD
video streaming, supporting long-time stable operation
2.Multi-platform compatibility: Adapt to Windows/Mac/Linux system
with universal USB interface, support Zoom/WeChat and other
software.
3.Plug and Play protocol: Quickly connect to your computer with
driver-free design, no need for complex setup to start live
streaming/conferencing.
4.13-megapixel sensor: Capture high-precision images with high
pixel count for detailed still life/commodity images, medical
images, etc.
Technical Parameters:
| Product Name | 13MP IMX258 Fixed Focus USB2.0 Camera Module |
Sensor | IMX258 |
Distortion | ＜-1.5% |
EFL | 3.57mm |
F.NO | 2.0±5% |
View Angle | D78.4° |
Focusing Range | 10cm to Infinity |
Chip Type | IMX258-AMH5-C |
Pixel Array | 4224H*3144V |
Lens Elements | 5P,Without 650nm IR |
Applications:
Office: Ideal for office environments that require high-definition
video conferencing and document shooting.
Monitoring: Due to its high resolution and stability, it is
suitable for security surveillance and video surveillance systems
Machine Vision: used for high-precision detection, positioning,
measurement, etc.
Industrial Testing: used for automated testing, quality monitoring,
part identification, etc.
Intelligent Transportation: used for license plate recognition,
traffic monitoring, violation capture, etc.
Medical Equipment: used for endoscopes, surgical aids, etc.
Research Experiments: used for high-speed motion capture,
microscopic imaging, etc.
Customized Process:
1. You can provide drawings or samples, as well as request
documentation and developed by our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat
product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time
to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need
to modify, mass production.
