OG02B10 HD Machine Vision 2MP USB Fixed Focus Camera Module 60FPS
Product Description:
The OG02B10 HD Machine Vision Camera module is a 2MP USB camera
specially designed for industrial automation. It supports
1080p@60FPS high-speed imaging and is equipped with a 1/2.9 inch
sensor and a 100° wide-angle field of view for high-speed
inspection, robot navigation and motion analysis. Its fixed focal
length design ensures optical stability, low latency data
transmission supports real-time processing, is compatible with
mainstream vision software platforms, and can be seamlessly
integrated into AI quality inspection and intelligent manufacturing
systems. Widely used in industrial automation, machine vision and
medical imaging fields.
Features:
1. High-definition high-speed imaging: 2 million pixels with 60FPS frame rate, can accurately capture
high-speed motion details, suitable for dynamic detection and robot
visual guidance.
2. Wide Angle coverage: 100° field of view Angle provides a wide range of monitoring field
of view, reducing the cost of multi-camera layout, suitable for
large-size workpiece detection scenes.
3. Optical stability: Fixed focal length design eliminates focus deviation, ensures
long-term imaging consistency, and improves the reliability of
detection equipment.
Technical Parameters:
| Product Name | OG02B10 Camera Module |
Sensor | OG02B10 |
Focusing Range | 6cm-15cm |
Module Size | 32mm*32mm |
Focus Type | FF |
Output | 1600*1300 |
Sensor Size | 1/2.9 Inch |
Frame Rate | 60FPS |
Interface Type | USB |
Brand Name | SINEREFIRST |
Applications:
Office: Ideal for office environments that require high-definition
video conferencing and document shooting.
Monitoring: Due to its high resolution and stability, it is
suitable for security surveillance and video surveillance systems
Machine Vision: used for high-precision detection, positioning,
measurement, etc.
Industrial Testing: used for automated testing, quality monitoring,
part identification, etc.
Intelligent Transportation: used for license plate recognition,
traffic monitoring, violation capture, etc.
Medical Equipment: used for endoscopes, surgical aids, etc.
Research Experiments: used for high-speed motion capture,
microscopic imaging, etc.
Customized Process:
1. You can provide drawings or samples, as well as request
documentation and developed by our engineering staff.
2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat
product you need and try to set the most suitable product for you
according to your needs.
4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time
to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need
to modify, mass production.
