0.3mp VGA Sensor Industrial Borescope Inspection Camera Module

Guangzhou Sincere Information Technology Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 0.3mp VGA Sensor Industrial Borescope Inspection Camera Module from wholesalers

    Buy cheap 0.3mp VGA Sensor Industrial Borescope Inspection Camera Module from wholesalers
    • Buy cheap 0.3mp VGA Sensor Industrial Borescope Inspection Camera Module from wholesalers
    • Buy cheap 0.3mp VGA Sensor Industrial Borescope Inspection Camera Module from wholesalers
    • Buy cheap 0.3mp VGA Sensor Industrial Borescope Inspection Camera Module from wholesalers
    • Buy cheap 0.3mp VGA Sensor Industrial Borescope Inspection Camera Module from wholesalers

    0.3mp VGA Sensor Industrial Borescope Inspection Camera Module

    Ask Lasest Price
    Brand Name : SINCERE FIRST
    Model Number : SF-C0310USB-D3.9-L20 V1.0
    Certification : CE, FCC, RoHS, REACH, ISO
    Price : Negotiable
    Payment Terms : L/C, Western Union, T/T, MoneyGram, Paypal and Others
    Supply Ability : 350000 pcs / month
    Delivery Time : 7 - 15 Work Days
    • Product Details
    • Company Profile

    0.3mp VGA Sensor Industrial Borescope Inspection Camera Module

    0.3mp VGA Sensor Industrial Borescope Inspection Camera Module

    0.3mp VGA Sensor Industrial Borescope Inspection Camera Module

    Product Description:

    The GC030A features 640V x 480H resolution with 1/10-inch optical format, and 4-transistorpixel structure for high image quality and low noise variations. It delivers superior image quality by powerful on-chip design of a 10-bit ADC,and embedded image signal processor.
    The full scale integration of high-performance and low-power functions makes the GC030A fit the design, reduce implementation process, and extend the battery life of cell phones, PDAs, and a wide variety of mobile applications.

    It provides RAW10 and RAW8 data formats with MIPI interface. It has a commonly used two-wire serial interface for host to control the operation of the whole sensor.

    Features:

    1. Standard optical format of 1/10 inch
    2. Output formats: Raw Bayer 10bit/8bit
    3. Power supply requirement: AVDD28:2.7~3.0V; IOVDD:1.7~1.9V,2.8V
    4. PLL support
    5. Windowing support
    6. ORE CON
    7. MIPI interface support
    8. Horizontal/Vertical mirror
    9. Package:CSP/COB/wafer

    Technical Parameters:

    Interface TypeUSB
    DSPUSB2.0 DSP
    SensorVGA Sensor
    Focusing Range20mm-60mm
    Focal Length1.72mm
    F Number3
    FOV(D)85°
    TV Distortion<-5%
    Led4pcs
    Warranty10 Years

    Applications:

    Scanning Bird Nests And Small Holes, Veterinary Endoscope, Sewer Detection, Laparoscope Equipments, Capsule Endoscopy

    0.3mp VGA Sensor Industrial Borescope Inspection Camera Module

    Customization:

    We can customize integrated or separate, diameter, steel sleeve, led, etc.

    0.3mp VGA Sensor Industrial Borescope Inspection Camera Module

    Why Choose us?

    0.3mp VGA Sensor Industrial Borescope Inspection Camera Module


    Customized Process:

    1. You can provide drawings or samples, as well as request documentation and developed by
    our engineering staff.

    2. Communication or Meeting
    3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you
    according to your needs.

    4. Sample Development
    5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
    6. Sample Testing
    7. Test and age on your application, feedback test results, no need to modify, mass production.


    About us:

    0.3mp VGA Sensor Industrial Borescope Inspection Camera Module

    Cooperative Brands & Customers:

    0.3mp VGA Sensor Industrial Borescope Inspection Camera Module

    Details Pictures:

    0.3mp VGA Sensor Industrial Borescope Inspection Camera Module0.3mp VGA Sensor Industrial Borescope Inspection Camera Module0.3mp VGA Sensor Industrial Borescope Inspection Camera Module
